62 Gallon Replacement Fuel Tank for 2011-2023 GM Duramax 6.6L Crew Cab Short Bed
62 Gallon Replacement Fuel Tank for 2011-2023 GM Duramax 6.6L Crew Cab Short Bed
SKU:10-1017
Regular price
$1,249.00 USD
Regular price
Sale price
$1,249.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Share
Product Description:
| Compatible with gooseneck and 5th wheel | Yes |
| Compatible with oe skid plate | No |
| Dimensions | 63.62" X 17.84" X 22.07" |
| Drain | No |
| Embedded fitting thread size | 1/2" NPT |
| Ground clearance compare to oe tank | 3.5" Lower |
| Sending unit | OE |
| Straps included | Yes |
| Sump | No |
| S&B Capacity (Approximate) | 62 gallons |
| Tank type | Midship |
| Transfer pump ready | Yes |
| Weight dry | 45lbs |
ALMOST DOUBLE YOUR RANGE.
S&B's 62-gallon fuel tank directly replaces the OEM 36-gallon tank without any cutting, drilling, or special modifications. This makes for a trouble-free, faster installation process. S&B's replacement fuel tank holds 5 more gallons than competitor tanks allowing you to save time, go further, and get more out of your truck!
LOCKED IN FOR A TRUE SEAL.
The S&B Fuel Tank was designed to use the OEM locking ring. This ensures a perfect seal and securely retains the fuel pump in the tank.
BUILT TO LAST.
S&B Tanks are made out of extremely strong crosslink polyethylene and backed by our lifetime warranty.
Important Note about the Fuel Gauge Operation:
-
The distance to empty (DTE) on GM trucks can’t be reprogrammed, so it will show about half the mileage that is really left. You can multiple the displayed range by 2 to find your actual range by 1.58 to find your range.
- The fuel gauge will operate properly. The fuel gauge will remain on full until about 4-5 gallons have been used and then the gauge will start to move normally. GM trucks monitor for an inoperative fuel gauge, so in some situations, until it starts to move, the truck’s computer will drop the gauge to empty to get the driver’s attention even though your tank is full. The gauge will return to its normal position after restarting the engine. We have seen cases when code P0463 appears due to the slow movement of the float, this can be cleared with a code reader. Once the fuel level drops 4-5 gallons from full, the fuel gauge will return to its normal operation
-
The bottom of the S&B tank has more surface area than the OE, so there will be a greater fuel reserve when the low fuel indicator comes on.
-
The nozzle at high-flow fuel stations(truck stops) will not be able to fill automatically.
Do you have an Auxiliary Fuel Tank? Read why using these with our tanks will void the Lifetime Warranty.
